Auto AC compressors 10P17/10PA17 SERIES (ISO/TS 16949:2002)

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V / 24V
W ( Power Consumption ) : 43
Breakaway Torque : 53
Weight : 6.7 / 6.9 kg

Auto A/C compressors 10PA15C/10P15 SERIES (ISO/TS 16949:2002)

Compressor:
Refrigerant : R134a
Num. of Cylinder : 10
cm3/r (Displacement) : 177
Lubrication Oil : PAG46
r/min (Max. Downshift Speed) : 7500
r/min (Max. Continuous Speed) : 6500

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V / 24V
W ( Power Consumption ) : 43
Breakaway Torque : 53
Weight : 6.7 / 6.9kg

Auto A/C Compressors 10S15 /10S17 SERIES (ISO/TS 16949:2002)

Compressor:
Refrigerant : R134a
Num. of Cylinder : 10
cm3/r (Displacement) : 177
Lubrication Oil : PAG46
r/min (Max. Downshift Speed) : 7000
r/min (Max. Continuous Speed) : 6000

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V / 24V
W ( Power Consumption ) : 43
Breakaway Torque : 53
Weight : 6.7 / 6.9kg

Auto AC compressors 507 SERIES(ISO/TS 16949:2002)

Compressor:
Num. of Cylinder : 5
Bore ( mm ) : 35
Stroke ( mm ) : 22.6
cm3/r (Displacement) : 108
r/min (Max. Downshift Speed) : 7000
r/min (Max. Continuous Speed) : 6000
Refrigerant : R12
Lubrication Oil : 5GS
Weight : 4

Magnetic Clutch:
Pulley ;: Fitted According to the requirements of users.
DC. V ( Rated Voltage ) : 12V
Breakaway Torque : 24.5
W ( Power Consumption ) : 42
Weight : 2.4

Auto air conditioner compressors 508 SERIES

Compressor:
Num. of Cylinder : 5
Bore ( mm ) : 35
Stroke ( mm ) : 28.5
cm3/r (Displacement) : 138
r/min (Max. Downshift Speed) : 7000
r/min (Max. Continuous Speed) : 6000
Refrigerant : R12
Lubrication Oil : 5GS
Weight : 5kg

Magnetic Clutch:
Pulley ;: Fitted According to the requirements of users.
DC. V ( Rated Voltage ) : 12V / 24V
Breakaway Torque : 34
W ( Power Consumption ) : 45
Weight : 2.8kg

Auto A/C compressors 5H11/5H14 SERIES (ISO/TS 16949:2002)

Compressor:
Refrigerant : R12 / R134a
Num. of Cylinder : 5
cm3/r (Displacement) : 108 / 138
Lubrication Oil : 5GS / PAG46
r/min (Max. Downshift Speed) : 7000
r/min (Max. Continuous Speed) : 6000

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V / 24V
W ( Power Consumption ) : 45
Breakaway Torque : 31.4
Weight : 7.3 / 7.8kg

Auto AC compressors 5V16 SERIES (ISO/TS 16949:2002)

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V/24V
W ( Power Consumption ) : 45
Breakaway Torque : 40
Weight : 6.6kg

Auto air conditioner compressors 6SE12 SERIES

Compressor:
Refrigerant : R134a
Num. of Cylinder : 5
cm3/r (Displacement) : 126
Lubrication Oil : PAG46
r/min (Max. Downshift Speed) : 8000
r/min (Max. Continuous Speed) : 7000

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V/24V
Weight : 5.2

Auto air conditioner compressors 6V12 SERIES

Compressor:
Refrigerant : R134a
Num. of Cylinder : 6
cm3/r (Displacement) : 10 ; 121
Lubrication Oil : PAG46
r/min (Max. Downshift Speed) : 8000
r/min (Max. Continuous Speed) : 7000

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V/24V
W ( Power Consumption ) : 43
Breakaway Torque : 35
Weight : 5.9

Auto A/C compressors 7B10 SERIES (ISO/TS 16949:2002)

Compressor:
Refrigerant : R12 / R134a
Num. of Cylinder : 7
cm3/r (Displacement) : 98
Lubrication Oil : 5GS / PAG46
r/min (Max. Downshift Speed) : 7000
r/min (Max. Continuous Speed) : 6000

Magnetic Clutch:
Dia. & Groove : Fitted According to the requirements of users.
DC. V ( Rated Volt. ) : 12V / 24V
W ( Power Consumption ) : 43
Breakaway Torque : 24
Weight : 4.5kg
