Description
technical data
Input: 220-250v AC 50Hz (1-p) Charging plug:SAE j1772
Main plug: None
Rated power: 7kw
Output: 220V-250V AC 32A
Number of phases: single phase Contact resistance: max.0.5 m 0
Insulation resistance: >500m 0(DC500V)
High voltage resistance: 2500V AC
Terminal temperature rise: <50k
Operating humidity: 5%-95% non condensing
Protection type: Charging gun head IP67 Executive standard: conformto SAE standard
Flame retardant grade: UL94 V-0|
Plugging force during coupling:45n
Operating temperature:-30 °C-120° C
Material application: terminal copper alloy, silver plated surface
Cable: 3*6mm2x0. 75mm2
Housing material: pc9330
Cable length weight: 5m (3kg)
Connector type: SAE type1
Display mode: None
Single packing specification:41cm*41cm*9.5cm
Customization instructions: from
5 meters /35yuan per meter[more than 10 pieces can be customized]
