380V DC charging pile

SKU: AC.530.021 Category:

Description

product properties:identify AC piles
Equipment size:1700*695*295mm[L*W*T)
Installation method:Wall mounted/floor mounted
“”
Wiring method:Next in line
“”
equipment weight:115KG/135KG
Cable long cable:5m
“”Input voltage:AC380V士15%
“”
Input frequency:50±5HZ
rated power:80KW
Steady flow accuracy:≤土1%
The output voltage:DC200-700V
Output current:110-220A
rated power:< 2W
Stablization accuracy:≤士5%
Safety standard:GB/T18487-2015
Ripple coefficient:≤+0.5%
Applicable environment:Indoor/outdoor
Operating temperature:-20*~50°C
Working humidity:Air-cooled
Operating altitude:< 2000m
Protection level:IP54
cooling method:Air-cooled
Harmonic current:≤5%
Charging efficiency:≥93%
