AC.530.023

SKU: AC.530.023 Category:

Description

product properties:identify AC piles
Equipment size:1700*700*400mm[L*W*T)
Installation method:Wall mounted/floor mounted
“”
Wiring method:Next in line
“”
equipment weight:125KG
Cable long cable:5m
“”Input voltage:AC380V士15%
“”
Input frequency:50±5HZ
rated power:120KW
Steady flow accuracy:≤土1%
The output voltage:DC200-700V
Output current:160A
rated power:< 2W Stablization accuracy:≤士5% Safety standard:GB/T18487-2015 Ripple coefficient:≤+0.5% Applicable environment:Indoor/Outdoor Operating temperature:-20*~50°C Working humidity:Air-cooled Operating altitude:< 2000m Protection level:IP54 cooling method:Air-cooled Harmonic current:≤5% Charging efficiency:≥93%
