SKU: AC.530.014 Category:


technical data
Input: 80-265v AC 50Hz (1-p) Charging plug: lec62196-2 type
Main plug: None
Rated power: 7kw
Output: 80-265v AC 32A
Number of phases: single phase Contact resistance: max.0.5 m 0
Insulation resistance: >500m Q(DC500V)
High voltage resistance: 2500V AC
Terminal temperature rise: <50k Operating humidity: 5%-95% non condensing Protection type: protection box IP55 Charging gun head IP67 Executive standard: conform to IEC standard Flame retardant grade: UL94 V-0| Plugging force during coupling: 45n 10000 times
Operating temperature:-30 °C-120° C
Material application: terminal copper alloy,silver plated surface
Cable: 3*6mm2x0.75mm2
Housing material: pc9330
Cable length weight: 5m (5kg)
Connector type: IEC type2
Display mode:indicator light
Single packing specification:41cm*41cm*13cm
Customization instructions: from
5 meters /35 yuan per meter
[more than 10 pieces can be customized]
